Context Rule

A context rule configures, for the identities of a given entity type, the generation of contexts which are used in provisioning to simplify the application of the role model's rules.

A context rule should be created for each entity type for which we want to assign entitlements automatically based on users' attributes.

Without a context rule, automatic entitlements (assigned via the role model's rules):

  • cannot be assigned based on users' attributes;
  • don't have specific start and end dates, so they are valid from the resource creation until its deletion.

See the Identity Lifecycle: Joiners, Movers and Leavers for additional information about context generation.

A context rule can be configured with Record Section in situations where a user needs to be modeled by several contexts over time or simultaneously.

Without record sections, a context rule can generate only one context per user. This means that users cannot have more than one contract, or position, at a time, and that data changes cannot be anticipated.

Examples​

The following example generates contexts, i.e. sets of dimension-value pairs, for users from Directory_User as resources of Directory_User:Records.

Both the start and end dates of the future contexts are defined with C# expressions based on users' contract and position start/end dates.

All contexts are to be made of the properties specified by the bindings B0 to B7.


<ContextRule Identifier="Directory_User" DisplayName_L1="Directory_User" Policy="Default" SourceEntityType="Directory_User" ResourcesBinding="Records" ResourcesStartExpression="C#:record:return record.StartDate ?? record.PositionStartDate ?? record.ContractStartDate;" ResourcesEndExpression="C#:record:return record.EndDate ?? record.PositionEndDate ?? record.ContractEndDate;"
    B0="Directory_UserRecord:Organization"
    B1="Directory_UserRecord:Title"
    B2="Directory_UserRecord:Site"
    B3="Directory_UserRecord:Site.Region.Country"
    B4="Directory_UserRecord:UserType.Category"
    B5="Directory_UserRecord:Organization.Type"
    B6="Directory_UserRecord:Subsidiary"
    B7="Directory_UserRecord:ExternalCompany"
/>

ExcludeExpression​

The following example is similar to the previous one, except that we choose to exclude users declared as "draft" from the role model and provisioning calculations.


<ContextRule Identifier="Directory_User" DisplayName_L1="Directory_User" Policy="Default" SourceEntityType="Directory_User" ResourcesBinding="Records" ResourcesStartExpression="C#:record:return record.StartDate ?? record.PositionStartDate ?? record.ContractStartDate;" ResourcesEndExpression="C#:record:return record.EndDate ?? record.PositionEndDate ?? record.ContractEndDate;" ExcludeExpression="C#:record:return record.IsDraft.GetValueOrDefault();"
    B0="Directory_UserRecord:Organization"
    B1="Directory_UserRecord:Title"
    B2="Directory_UserRecord:Site"
    B3="Directory_UserRecord:Site.Region.Country"
    B4="Directory_UserRecord:UserType.Category"
    B5="Directory_UserRecord:Organization.Type"
    B6="Directory_UserRecord:Subsidiary"
    B7="Directory_UserRecord:ExternalCompany"
/>

This option can exclude workers who are not validated yet, or who have left the company, for example.

RiskFactorType​

The following example is similar to the previous one, except that we force the final risk score of a user to be the maximum value of all their risk scores.


<ContextRule Identifier="Directory_User" DisplayName_L1="Directory_User" Policy="Default" SourceEntityType="Directory_User" ResourcesBinding="Records" ResourcesStartExpression="C#:record:return record.StartDate ?? record.PositionStartDate ?? record.ContractStartDate;" ResourcesEndExpression="C#:record:return record.EndDate ?? record.PositionEndDate ?? record.ContractEndDate;" ExcludeExpression="C#:record:return record.IsDraft.GetValueOrDefault();" RiskFactorType="Max"
    B0="Directory_UserRecord:Organization"
    B1="Directory_UserRecord:Title"
    B2="Directory_UserRecord:Site"
    B3="Directory_UserRecord:Site.Region.Country"
    B4="Directory_UserRecord:UserType.Category"
    B5="Directory_UserRecord:Organization.Type"
    B6="Directory_UserRecord:Subsidiary"
    B7="Directory_UserRecord:ExternalCompany"
/>

Role mining​

Context rules also contain some parameters for Perform Role Mining .

Users are distributed in a hypercube made of all dimensions, like in the following table (left) when we have only 2 dimensions, where for example 1, 2, 3, etc. are users' possible locations, and A, B, C, etc. are users' possible departments in the company. When considering one dimension and sorting the dimension values per user percentage, we get the following table (right).

Role Mining Tables

The tables here represent a simple situation with few dimensions. But the higher the number of dimensions, the more complex are role mining's computations. This is known as the curse of dimensionality.

The following example is similar to the first one, except that we customize some role mining parameters which help tackle the curse of dimensionality:

  • MinIdentitiesCount establishes that the role mining's engine will generate a role assignment rule only when the rule is applicable to at least 5 users;

  • ReductionOutlierPercentage establishes that the role mining's engine will consider the last 2.0% dimension values (from Y to Z in the table above) to be grouped together in a single category "Others".

    The definition of the outlier percentage is particularly useful when managing, for example a services company with thousands of distinct organizations, where many organizations contain only one or two users. We can safely choose to group into a single fictitious organization the 2% of all users that involve the smallest organizations.


<ContextRule Identifier="Directory_User" DisplayName_L1="Directory_User" Policy="Default" SourceEntityType="Directory_User" ResourcesBinding="Records" ResourcesStartExpression="C#:record:return record.StartDate ?? record.PositionStartDate ?? record.ContractStartDate;" ResourcesEndExpression="C#:record:return record.EndDate ?? record.PositionEndDate ?? record.ContractEndDate;" MinIdentitiesCount="5" ReductionOutlierPercentage="2.0"
    B0="Directory_UserRecord:Organization"
    B1="Directory_UserRecord:Title"
    B2="Directory_UserRecord:Site"
    B3="Directory_UserRecord:Site.Region.Country"
    B4="Directory_UserRecord:UserType.Category"
    B5="Directory_UserRecord:Organization.Type"
    B6="Directory_UserRecord:Subsidiary"
    B7="Directory_UserRecord:ExternalCompany"
/>

Certification items​

Unlike ResourcesStartBinding and ResourcesEndBinding, ResourcesStartExpression and ResourcesEndExpression cannot be used to define the resources to include in the related certification campaigns. Thus, when needing to define which resources to include with more than start/end bindings, add a comparison based on ResourceCertificationComparisonBinding, ResourceCertificationComparisonOperator and ResourceCertificationComparisonValue.

The following example includes in certification campaigns only the resources that have their IsActivePosition property set to 1.


<ContextRule Identifier="Directory_User" DisplayName_L1="Directory_User" Policy="Default" ResourcesBinding="Records" ResourcesStartExpression="C#:record:return record.StartDate ?? record.PositionStartDate ?? record.ContractStartDate;" ResourcesEndExpression="C#:record:return record.EndDate ?? record.PositionEndDate ?? record.ContractEndDate;" SourceEntityType="Directory_User" ExcludeExpression="C#:record:return record.IsDraft.GetValueOrDefault();" RiskFactorType="Max" ResourceCertificationComparisonBinding="Directory_UserRecord:IsActivePosition" ResourceCertificationComparisonOperator="Equal" ResourceCertificationComparisonValue="1"
    B0="Directory_UserRecord:Organization"
    B1="Directory_UserRecord:Title"
    B2="Directory_UserRecord:Site"
    B3="Directory_UserRecord:Site.Region.Country"
    B4="Directory_UserRecord:UserType.Category"
    B5="Directory_UserRecord:Organization.Type"
    B6="Directory_UserRecord:Subsidiary"
    B7="Directory_UserRecord:ExternalCompany"
/>

Note: must be configured together with the other ResourceCertificationComparison properties.

Note: when not specified, certification items are defined by ResourcesStartBinding and ResourcesStartBinding.

Properties​

PropertyDetails
B0 optionalType Int64 Description Binding of the dimension 0 (up to 3V in Base32 Parameter Names ). The dimension can then be used in rules to filter the rules' targets.
DisplayName_L1 requiredType String Description Display name of the context rule in language 1 (up to 16).
ExcludeExpression optionalType String Description C# expression that defines the resources to exclude from context generation, because they should not be part of the role model and provisioning calculations. See the Expressions topic for additional information.
Identifier requiredType String Description Unique identifier of the context rule.
MinIdentitiesCount default value: 0Type Int32 Description Minimum number of identities to take into account to generate a rule by the role mining engine.
Policy requiredType Int64 Description Identifier of the policy that the rule is part of.
ReductionOutlierPercentage default value: 0.0Type Float Description Proportion of identities that are grouped together by role mining to aggregate all the small entities in one "other" category. This is used to speed up the mining process as the number of groups can be greatly reduced.
ResourceCertificationComparisonBinding optionalType Int64 Description Binding of the property whose value is to be compared to ResourceCertificationComparisonValue in order to specify the resources to include in the related certification campaigns. Note: must be configured together with the other ResourceCertificationComparison... properties. Note: when not specified, certification items are defined by ResourcesStartBinding and ResourcesStartBinding. And when they are not specified either, there is no filtering, so all valid resources (those with ValidTo later than today's date) are included.
ResourceCertificationComparisonOperator optionalType QueryComparisonOperator Description Operator of the comparison that specifies the resources to include in the related certification campaigns. Note: must be configured together with the other ResourceCertificationComparison... properties. Note: when not specified, certification items are defined by ResourcesStartBinding and ResourcesStartBinding. And when they are not specified either, there is no filtering, so all valid resources (those with ValidTo later than today's date) are included.
ResourceCertificationComparisonValue optionalType String Description Value to be compared to the value of ResourcesCertificationComparisonBinding in order to specify the resources to include in the related certification campaigns. Note: must be configured together with the other ResourceCertificationComparison... properties. Note: when not specified, certification items are defined by ResourcesStartBinding and ResourcesStartBinding. And when they are not specified either, there is no filtering, so all valid resources (those with ValidTo later than today's date) are included.
ResourcesBinding optionalType Int64 Description Binding that represents the entity type of the contexts to be created from the SourceEntityType. It can also be defined via ResourcesExpression.
ResourcesEndBinding optionalType Int64 Description Binding of the date property among those from ResourcesBinding which specifies the end of validity for all Record Section properties of the context. It can also be defined via ResourcesEndExpression. Note: a context rule's start and end dates are ignored when the related identities are also configured with Record Section .
ResourcesEndExpression optionalType String Description Expression based on the ResourcesBinding entity type that defines the end of validity for all Record Section properties of the context. It can also be defined via ResourcesEndBinding. See the Expressions topic for additional information. Note: a context rule's start and end dates are ignored when the related identities are also configured with Record Section .
ResourcesExpression optionalType String Description Expression based on SourceEntityType that defines the entity type of the contexts to be created. It can also be defined via ResourcesBinding. See the Expressions topic for additional information.
ResourcesStartBinding optionalType Int64 Description Binding of the date property among those from ResourcesBinding which specifies the beginning of validity for all Record Section properties of the context. It can also be defined via ResourcesStartExpression. Note: a context rule's start and end dates are ignored when the related identities are also configured with Record Section .
ResourcesStartExpression optionalType String Description Expression based on the ResourcesBinding entity type that defines the beginning of validity for all Record Section properties of the context. It can also be defined via ResourcesStartBinding. See the Expressions topic for additional information. Note: a context rule's start and end dates are ignored when the related identities are also configured with Record Section .
RiskFactorType optionalType RiskFactorType Description Operator used to aggregate a user's risk scores together to compute the user's global risk score. 0 - None. 1 - Max: a user's final risk score is the maximum value among all their risk scores. 2 - Average: a user's final risk score is the average value of all their risk scores.
SourceEntityType requiredType Int64 Description Identifier of the entity type of the parent resource.
