Various XML Settings

This section describes Identity Manager's Settings available in the applicative configuration. Those are mandatory.

ConfigurationVersion​

This setting is used to track the current configuration version.


    <ConfigurationVersionSetting Version="5.0.0" Description="Demo IdentityManager" />

  • Version defines the configuration version.
  • Description describes this version in detail.
  • Misc misc.

AppDisplay​

This setting is used to customize the application display.


    <AppDisplaySetting PrimaryColor="#009597" SecondaryColor="#00553F" ApplicationName="Usercube" LogoFile="Images/logo.webp" FaviconFile="Images/favicon.ico" />

  • PrimaryColor defines the primary color.
  • SecondaryColor defines the secondary color.
  • BannerColor defines the banner (header displaying logo and navigation bar) color.
  • BannerTextColor defines the banner text color.
  • ApplicationName defines the application name.
  • LogoFile defines the logo path. Concerning the logo, for an ideal result, the following ratio should be used: 5:1.
  • LogoMimeType defines the logo mime type.
  • FaviconFile defines the favicon path.
  • FaviconMimeType defines the favicon mime type.
  • FullNameSeparator defines the full name separator (default value is �).
  • DisableProvisioningCounters disables the counters related to the provisioning screens (Role Review, Provisioning Review, Role Reconciliation, Resource Reconciliation and Manual Provisioning - default value is false).

This setting enables the configuration of custom links that let the user navigate to a custom static HTML page. Only two CustomLinkSetting can be configured.

The example below defines two custom links accessible through the URLs "your-Identity Manager-domain/LegalNotice" and "your-Identity Manager-domain/TermsOfService", each showing the content of the corresponding HTML file depending on the currently selected language.


    <CustomLink1Setting Url="/LegalNotice" Path_L1="LegalNotice_en.html" Path_L2="LegalNotice_fr.html" />    <CustomLink2Setting Url="/TermsOfService" Path_L1="TermsOfService_en.html" Path_L2="TermsOfService_fr.html" />

  • Url_(required)_ defines the url address from which to access the custom page.
  • PathL1(required)_ defines the path (from the configuration root) to the HTML file to be rendered depending on the currently selected language in the user interface (Path_L1 to Path_L16 are available). Only Path_L1 is required. While navigating to a custom link, if no HTML path was defined for the current language, then Path_L1 is taken as default.


To navigate to the custom links from the user interface, NETWRIX recommends configuring a MenuItem with a URI value matching the custom link URL. The following example defines two menu items, accessible from the user account tab in the top right corner of the interface, that allows the user to navigate to the defined URI addresses.


    <MenuItem Identifier="UserMenu_CustomLink1" DisplayName_L1="Legal Notice" DisplayName_L2="Mentions l�gales" IconCode="List" URI="/LegalNotice" ParentMenuItem="UserMenu" />    <MenuItem Identifier="UserMenu_CustomLink2" DisplayName_L1="Terms of Service" DisplayName_L2="Conditions d'utilisation" IconCode="List" URI="/TermsOfService" ParentMenuItem="UserMenu" />


DashboardItemNumber​

Some sections on the dashboard contain multiple links. These links are quick links with counters to the review page filtered by entity type. The links are sorted by entity type priority.


By default, 3 links are displayed. If more than 3 entity type links exist, a link "Others" is displayed with the concatenation of remaining counters.

This setting is used to customize the number of links to displayed on each section.

The max number of links to display is 5.


<DashboardItemNumberSetting RoleReviewSection="2" ProvisioningReviewSection="5" RoleReconciliationSection="2" ResourceReconciliationSection="2" MyTasksSection="4" ManualProvisioningSection="2" />

  • RoleReviewSection defines the number of links to display in the "Role Review" section.
  • ProvisioningReviewSection defines the number of links to display in the "Provisioning Review" section.
  • RoleReconciliationSection defines the number of links to display in the "Role Reconciliation" section.
  • ResourceReconciliationSection defines the number of links to display in the "Resource Reconciliation" section.
  • ManualProvisioningSection defines the number of links to display in the "Manual Provisioning" section.
  • MyTasksSection defines the number of links to display in the "My Tasks" section.

SelectUserByIdentityQueryHandler​

This attribute matches an end-user with a resource from the unified resource repository.

Authorization mechanisms within Identity Manager rely on assigning Profiles to an identity-resource that stands for the end-user digital identity.

To that end, and end-user authentication credentials are linked to such an identity-resource using the following pattern:

  1. Authentication credentials are retrieved;
  2. Authentication credentials are trimmed using the AfterToken and/or BeforeToken attributes;
  3. The trimmed result is matched against the ResourceIdentityProperty of resources with an EntityType OwnerEntityType;
  4. The matching resource found is used to find a profile and authorization for that digital identity.

Attributes

  • ResourceIdentityProperty is the identity-resource property supposed to match the authentication login used by the end-user.

  • OwnerEntityType is the entity type of the resources used to store digital identities within Identity Manager.

  • BeforeToken_(optional)_ defines the first character used to trim the authentication login.

  • AfterToken_(optional)_ defines the second character used to trim the authentication login.

    The trimmed result is the content of the authentication login between AfterToken and BeforeToken. If BeforeToken is empty, trimmed result is everything after AfterToken. If AfterToken is empty, trimmed result is everything before BeforeToken.

  • ResourceDisplayNameProperty is the property used for displaying login data at the top right of the application.

  • OwnerPhotoTagProperty defines the photo property for Identity Manager users.

Example

The following example links the authentication credentials of an end-user to its matching resource of EntityType Directory_User.

In this example, authentication has been set up using End-User Authentication. In that case, the login used by the end-user is in the form DOMAIN/userName.

The AfterToken attribute parses the DOMAIN/userName string into userName.

The parsed result userName is compared with AD_Entry:sAMAccountName property value of Directory_User resources.

The matching Directory_User resource is the resource that stands for the end-user identity within Identity Manager.


<SelectUserByIdentityQueryHandlerSetting
    ResourceIdentityProperty="AD_Entry:sAMAccountName"
    ResourceDisplayNameProperty="AD_Entry:displayName"
    OwnerPhotoTagProperty="Directory_User:PhotoTag"
    OwnerEntityType="Directory_User"
    AfterToken="\"/>

SelectPersonasByFilterQueryHander​

This setting is used to filter the entity type used by authentication mechanism.


    <SelectPersonasByFilterQueryHanderSetting ResourceDisplayNameProperty="AD_Entry:displayName" PersonTypeFilterProperty="AD_Entry:objectCategory" PersonTypeFilter="Person" />

  • ResourceDisplayNameProperty represents the display property.
  • OwnerPhotoTagProperty defines the photo tag property.
  • PersonTypeFilterProperty defines the filter property.
  • PersonTypeFilter defines the filter value.
  • MailProperty defines the mail property.

SelectAllPerformedByAssociationQueryHandler​

This setting enables task delegation to a group of people.


 <SelectAllPerformedByAssociationQueryHandlerSetting RootEntityType="AD_Entry" Binding="member" />

  • RootEntityType indicates the entity type on which the delegation is applied.
  • Binding defines the binding used to get the list of identities to delegate to.

NB: In order for delegation to work, users that are part of the delegate group must have at least one assigned profile

Scheduling CleanDataBase​

If the default value for the Task CleanDataBase needs to be overridden, define this setting:


    <SchedulingCleanDataBaseSetting Timeout="2" CronTabExpression="* */2 * * *"/>

  • Timeout: Defines the maximum time a Job or Task can wait after the last run.
  • CronTabExpression: Define the cron to launch the CleanDatabase Job.

7. Password Generation Setting​

It is possible to override some aspects of the password generation (used in password reset features) using the following setting:


    <PasswordGenerationSetting AllowedSymbolChars="*@!^-_" />

  • AllowedSymbolChars: A string containing the list of symbol chars to be used in the generated password. The default value is : !;.,?()[]-_&%$+{}@
