Application Settings

What the Application Tab Holds

Settings > Application is where deployment-wide defaults live. There are two cards: Classification and Netwrix Activity Monitor. At the bottom of the Netwrix Activity Monitor card, Admins also see an Enrollment token panel. Admins can change everything on the tab. Viewers can open the tab and edit fields, but their saves fail with the message Some settings weren't saved.

Each row is one setting. The row label is the setting's key, exactly as the following tables give it, with a one-line description underneath. Two badges can appear next to the key:

• Overridden means the saved value differs from the shipped default.
• Modified means you've edited the value but haven't saved yet.

Number fields show their allowed range as a hint under the field. Any row whose value differs from the shipped default also gets a reset icon; see Reset a setting to its default.

As soon as you edit a row, a bar appears at the bottom of the page. It counts your edits (1 unsaved change, 3 unsaved changes) or, if a value is invalid, names the field (1 field has an invalid value: followed by the key). You can't save while a field is invalid.

Change a Setting

1. Go to Settings > Application.
2. Edit the setting. For a number, enter the new value; for an extension list, see Edit an extension list.
3. Correct any field the bar flags as invalid.
4. Click Save changes, or press Ctrl+S (Cmd+S on a Mac).

A message confirms the result: 1 setting saved or 3 settings saved. If any value fails to save, the message reads Some settings weren't saved.

To drop every unsaved edit, click Discard. If you navigate away with unsaved edits, an Unsaved changes dialog asks "You have unsaved changes that will be lost if you leave. Are you sure you want to leave?" Click Stay to keep editing or Leave to drop the edits.

Validation Messages

Message	Cause
Value is required	The field is empty.
Must be a whole number	The value has a decimal point or non-numeric characters.
Must be between {min} and {max}	The value is outside the setting's range.

Edit an Extension List

The extension lists are chip editors: each extension is a separate chip in the field.

To add an extension:

1. Click the field.
2. Enter the extension, for example .bak.
3. Press Enter.

To remove an extension, click the remove icon on its chip, or press Backspace.

Pasting text separated by spaces, commas, or semicolons adds one chip per extension. The editor drops duplicates, ignoring case, so .PDF and .pdf count as the same entry.

Reset a Setting to Its Default

When a value differs from the shipped default, a reset icon appears on the row. Its tooltip reads Reset to default, followed by the default value in parentheses for number settings.

1. Click the reset icon on the row. The default value appears in the field. If the row shows Overridden, it also shows Modified until you save.
2. Click Save changes.

Classification

These defaults govern how Sensitive data scans classify content. You can override one of them, the worker count, per scan; the rest apply everywhere.

Setting	Default	Range	What it affects
classification_workers_default	15	1–50	Default number of concurrent classification workers per scan. Applies when a Sensitive data scan doesn't set its own Workers value.
file_server_excluded_extensions	See the default list	—	File extensions to skip when classifying File Server content. Matching is case-insensitive. An empty list excludes nothing.
file_server_file_size_max_mb	10	1–100	Maximum file size, in MB, to classify for File Server sources. Scans skip larger files.
sharepoint_excluded_extensions	See the default list	—	File extensions to skip when classifying SharePoint Online content. Matching is case-insensitive.
sharepoint_file_size_max_mb	10	1–100	Maximum file size, in MB, to classify for SharePoint Online sources. Scans skip larger files.

A Sensitive data scan on a File Server source has its own Workers field (1–20), which shows 3 by default. If you leave it at 3, the scan uses classification_workers_default. If you change it, the scan saves your value and uses it instead of the global default. See Scan types.

The two extension lists ship with media, binaries, fonts, disk images, and similar files that rarely carry text worth classifying. The SharePoint Online list adds web-page formats on top of the File Server list.

Default value of file_server_excluded_extensions

.aac .aiff .asd .avi .bat .bin .bmp .cab .cdf-ms .chm .cmd .com .cpl .cur .dib
.dll .dmg .dmp .drv .eot .exe .flac .flv .gfa .gif .giff .heic .heif .hlp .ico
.img .iso .jfi .jfif .jif .jpe .jpeg .jpg .lnk .m4a .m4v .mkv .mov .mp3 .mp4
.mpeg .mpg .msi .msp .otf .ova .ovf .pdb .png .qcow2 .scr .svn-base .sys .tif
.tiff .tmp .ttf .vdi .vhd .vhdx .vmdk .wav .wbk .webm .webp .wim .wma .wmv
.woff .woff2

Default value of sharepoint_excluded_extensions

Everything in the File Server list, plus:

.asp .aspx .css .htm .html .url .xaml

Netwrix Activity Monitor

These settings tune the listener that Netwrix Activity Monitor agents connect to. For the integration itself, see Netwrix Activity Monitor.

Setting	Default	Range	What it affects
activitymonitor_connection_timeout	900	5–3600	Seconds of inactivity before the listener drops an idle Netwrix Activity Monitor client.
activitymonitor_enrollment_ban_duration_seconds	10	5–300	Seconds to ban a source IP after it presents an invalid enrollment code.
activitymonitor_enrollment_first_message_timeout_seconds	10	5–60	Seconds to wait for the first message from a newly connected Netwrix Activity Monitor agent.
activitymonitor_max_message_size	16777216	65536–67108864	Maximum size in bytes of a single Netwrix Activity Monitor message. The default is 16 MB.

Enrollment Token

Only Admins see the Enrollment token panel. Click Generate token to issue a token. The token appears in a read-only field with a copy icon, followed by Expires: and the expiry time. A token is valid for 1 hour.

After the first token, the button reads Generate new token. Each new token invalidates the one before it, so give the current token to the person enrolling the agent before you generate another.

If the panel is disabled and shows NAM listener certificate isn't configured on this server, the Netwrix Activity Monitor (NAM) listener has no TLS certificate yet. Netwrix Activity Monitor covers that setup and how the agent uses the token.

When Changes Take Effect

You don't need to restart anything. Services pick up new values within 5 minutes. Classification settings apply to Sensitive data scans that start after the services pick up the new value, which can take up to 5 minutes; a running scan keeps the values it started with. Netwrix Activity Monitor settings apply to connections opened after the change; Activity Monitor agents already connected keep their current session.
